ZCL 360i; 90W RGBW 360 moving head w/ Zoom

The Elation Pro Lighting ZCL 360i™ is a powerful single beam moving effect luminaire with zoom centered around a single 90W RGBW 4-in-1 LED and the new advanced collimator optic lens, which produces a laser-like homogenized 4° color-changing beam. Features include 4° to 44° motorized zoom, fast and precise16-bit continuous full 360° pan and tilt rotation, electronic strobe, dimmer, and selectable dimming curve effects. Controlling the ZCL 360i is done thru DMX, RDM (Remote Device Management), KlingNET™, and Art-NET support, 5pin XLR, RJ45 etherCON, and powerCON in/out connections. This fixture also offers a (7) button control full color 180° reversible menu display, multiple unit power linking, boasts flicker free operation for TV and FILM, and a multi-voltage universal auto switching power supply (100-240v).

Features

• Powerful 4° Single Beam Moving Effect Luminaire with Zoom
• 90 W RGBW 4-in-1 LED
• 4° to 44° Motorized Zoom
• New Advanced Collimator Optic Lens
• Laser-Like Homogenized Color Changing Beam
• Fast and Precise 16-Bit Continuous 360° Pan/Tilt Rotation
• Flicker Free Operation for Broadcast TV and FILM

Specifications

• Source:
  • 90 W RGBW 4-in-1 LED
  • 100,000 Hour Average LED Life
• Photometric Data:
  • 11,123 LUX 1,033 FC @ 9.8 ft (3m) (4° Min Zoom) Full ON
  • 483 LUX 45 FC @ 9.8 ft (3m) (44° Max Zoom) Full ON
• Color: RGBW
• Effects:
  • RGBW Color Mixing
  • 4° - 44° Beam Zoom Range
  • Variable Dimming Curves
  • Electronic Strobe and Dimming (0% - 100%)
  • 64 Color Presets and 14 Unique Color Macros
• Control/Connections:
  • (3) DMX Channel Modes (21 Total Channels)
  • RDM (Remote Device Management)
  • (7) Button Touch Control Panel
  • Full Color 180° Reversible LCD Menu Display
  • 8 / 16 Bit Resolution Adjustable Movement
  • 5pin XLR In/Out
  • RJ45 etherCON In/Out (KlingNET™ / Art-NET)
  • powerCON Power In/Out
• Dimensions (LxWxH): 8.74” x 7.31” x 13.22” (222.1 x 186 x 336 mm)
• Weight: 13 lbs. (5.9 kg)
• Electrical/Thermal:
  • AC 100-240 V - 50/60 Hz
  • 101W Max Power Consumption
  • 5° F to 113° F (-15° C to 45° C)
• Approvals/Ratings: CE | RoHs | IP30
