Elation Lighting

SMARTY MAX; 470W CMY Spot, Beam, Wash

SMARTY MAX; 470W CMY Spot, Beam, Wash

Regular price $6,800.00 USD
Regular price $9,500.00 USD Sale price $6,800.00 USD
Sale Sold out
The SMARTY MAX combines high output and long lamp life in a feature packed compact and lightweight Hybrid fixture. SMARTY MAX is the Extreme Output Hybrid featuring the new Philips MSD Platinum FLEX 400 lamp and Elation's 2 year / 4,000 hours Ultimate Warranty.** Rated at 480W and up to 4,000 hours smart lamp life the SMARTY MAX includes CMY and variable CTO and is the world’s first Hybrid incorporating a full Iris for dynamic beam effects. Four prisms on two planes, dual frosts plus dual gobo wheel and the unique dual track animation round out the comprehensive FX package in a compact and lightweight housing. Delivering 21,000 lumens from its large 160mm front aperture, the SMARTY MAX has a crisp output for extremely powerful beams, sharp gobos and bright washes, making it a flexible fixture for almost any application, while providing an excellent return on investment.


Features

  • Extreme Output 3-in-1 Beam, Spot, Wash Hybrid Fixture
  • Flex Lamp Technology from 370 to 480W plus Smart Hibernation with up to 4,000 Hour Lamp Life
  • Full CMY Color Mixing System, Variable CTO, Color Wheel
  • Creative FX Package: 8 Rotating and 14 Static Gobos, Dual Track Animation, Iris 4x Prism on Dual Planes, 2x Frost
  • Ultra-Fast Zoom: Beam 2° - 20° | Spot 3° - 30° | Wash 9° - 35°
  • 2 Years / 4,000 Hours Ultimate Warranty**
  • **First 2 Years of operation or 4,000 hours of use, whichever comes first, based on regular fixture/lamp maintenance.

Specifications

SOURCE

  • Philips MSD Platinum 400 Flex 480W Lamp
  • Variable Lamp Power 370/470/480W
  • Automated Lamp Hibernation with Instant Recovery
  • Up to 4,000 Hour Lamp Life*
  • *Test lab conditions. May vary depending on several factors including but not limited to:
  • Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling),Control, and Dimming.



PHOTOMETRIC DATA

  • 21,000+ Lumen Total Fixture Output
  • 1.5° Beam: 1,784,448 LUX (165,781 FC) @5m (16.4ft)
  • 3° Spot: 462,508 LUX (42,968 FC) @5m (16.4ft)

Beam

  • Zoom Range 2° - 20°
  • Beam Angle 0.8° - 6.5°
  • Field Angle 1.8° - 16.2°

Spot

  • Zoom Range 3° - 30°
  • Beam Angle 1.7° - 14.8°
  • Field Angle 3° - 26.5°

Wash

  • Zoom Range 9° - 35°
  • Beam Angle 6.8° - 29°
  • Field Angle 12.8° - 39.4°



EFFECTS

  • Beam, Spot and Wash Modes
  • Motorized Zoom
  • Dual Frost Filter for Light Frost/ Full Wash
  • 4 Prisms on Dual Planes
  • Iris
  • CMY Color, Gobo, Prism Macros
  • Motorized Focus with Auto-Focus Feature
  • High Speed Shutter and Strobe



COLOR

  • Full CMY Color Mixing System
  • Variable CTO
  • 13 Position Color Wheel



GOBOS

  • 2 Gobo Wheels
  • 8 Interchangeable-Rotating / Indexing Glass Gobos
  • 14 Static-Stamped Metal Gobos
  • Dual Track Animation Wheel



CONTROL / CONNECTIONS

  • 2 DMX Channel Modes (27 / 44 Channels)
  • (6) Button Touch Panel
  • Full Color 180° Reversible LCD Menu Display
  • DMX, RDM, Art-Net and sACN Protocol Support
  • 5pin DMX In/Out
  • RJ45 Ethernet In/Out
  • IP65 Locking Power Cable In/Out
  • With Wired Digital Communication Network



SIZE / WEIGHT

  • Length: 15.34” (389.8mm)
  • Width: 17.53” (445.3mm)
  • Height: 25.27” (642mm)
  • Weight: 60.0 lbs. (27.2kg)



ELECTRICAL / THERMAL

  • AC 100-240V 50/60Hz
  • 700 W Max Power Consumption (estimated)
  • 14°F to 113°F (-10°C to 45°C)
  • BTU/hr (+/- 10%) 2387
