Fuze Profile; 305W RGBMA Full Color Spectrum LED + Framing

From theater to television and many other precision lighting applications, the FUZE PROFILE™ from Elation is an automated LED framing fixture that brings sharpness to your displays. Powered by a 92 CRI engine with a 5-color homogenized LED array (Red, Green, Blue, Mint, and Amber sources), accurate color reproduction is delivered by 9,000+ lumen output. Illuminate immediately and impressively, designers can explore the virtual color temperature, Magenta / Green adjustment plus color gel emulation are included. Illuminate with accurate framing and outstanding color quality wherever fully automated ellipsoidal illumination is required. FUZE PROFILE also features a rotating gobo wheel of breakups, two color wheels featuring solid colors and correction filters plus and Iris in this quiet, compact, lightweight fixture.

Features

• Extended color RGBMA LED Engine, 92 CRI
• Rotating and Fixed Gobo plus Animation Wheel
• Full Blackout Framing System
• Wide Zoom Range from 7° to 46°

Specifications

• Source:
  • 305W 6,500K RGBMA LED Engine, 92 CRI
  • 30,000 Hour Average LED Life*
  • *May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling),Control, and Dimming.
• Photometric Data: 9,000+ Total Lumen Output
• Effects:
  • 7° - 46° Motorized Zoom
  • 4 Rotating Full Blackout Framing Blades, +/- 45 Index
  • Variable Frost Filter
  • 4 Facet Prism
  • Motorized Iris
  • Variable 16-bit Dimming Curve Modes
  • High Speed Electronic Shutter and Strobe
• Color:
  • RGBMA Color Array
  • CMY Emulation
  • Virtual Color Correction
  • Green/Magenta Shift
  • Virtual Gel Swatch Book
• Gobos:
  • 1x 6 Rotating / Indexing Interchangeable Glass Gobos
  • 1x 7 Fixed Glass Gobo
  • Animation Wheel
• Conrol/Connections:
  • 2 DMX Channel Modes
  • 16-bit Pan, Tilt, and Dimming Control
  • DMX Adjustable LED Frequency
  • DMX, RDM Protocol Support
  • 4 Button Touch Control Panel
  • Full Color 180° Reversible LCD Menu Display
  • 16 Bit Resolution Adjustable Movement
  • 5pin DMX In/Out
  • Neutrik powerCON TRUE1 Power In/Out
  • With Wired Digital Communication Network
• Electrical/Thermal:
  • AC 100-240V - 50/60Hz
  • W Max Power Consumption
  • 14°F to 113°F (-10°C to 45°C)
• Approvals/Rating: CE | cETLus pending | IP20
• Dimensions: 16" x 10.1" x 27.4"
• Weight: 55.1 lbs.

Note

Specifications and Images are preliminary per vendor (Spring 2019). Please contact your Full Compass Sales Pro for assistance with any questions!
