Fuze MAX Spot; 800W RGBMA Full Color Spectrum LED Spot

Elation's FUZE MAX SPOT is an automated LED Spot fixture that has been designed to cater to the lighting needs of theaters, television, and a range of other precision lighting applications. Its 92 CRI engine is powered by an 800 W 5-color homogenized LED array consisting of red, green, blue, mint, and amber sources that are carefully tuned to deliver accurate color reproduction and dynamic whites while providing an impressive output of over 21,000 lumens. The fixture also boasts of virtual color temperature, Magenta/Green adjustment, and CMY emulation, offering the designer immediate access to its impressive LED color array. Additionally, the FUZE SPOT MAX features two rotating gobo wheels, a fixed gobo wheel, animation wheel, dual frost, prism, and iris, making it a comprehensive and powerful automated spot fixture that is perfect for any application where outstanding and compelling color range and quality is required. Despite its powerful output, the fixture operates quietly.

Elation FUZE MAX SPOT Includes:

• FUZE MAX SPOT RGBMA LED Spot Fixture
• 2 Omega Brackets
• IP65 Rated Twist-Lock Power Cable

Elation FUZE MAX SPOT Features:

• Full Spectrum 800W RGBMA LED Engine
• Precise dynamic whites from 2400 - 8500K
• Instant color changes, Natural color transitions
• Rich and intense primary colors
• Dual Rotating and Fixed Gobos plus Animation Wheel
• Iris, Prism, and Dual Frost
• Wide Zoom Range from 7° to 53°
• Large 140 mm front aperture

Elation FUZE MAX SPOT Specifications:

• Source
  • LED Engine: 800W 6,500K RGBMA
  • Average LED Life: 30,000 Hours
  • Photometric Data
  • Total Lumen Output: 21,000
  • CRI: 92
  • Zoom Range: 7° - 53°
  • Beam Angle: 6.6° - 50.3°
  • Field Angle: 7.8° - 55°
• Effects
  • Zoom: Motorized
  • Dual Variable Frost Filter: Medium/ Wash
  • Prism: 4 Facet Round, 4 Facet Linear
  • Iris: Motorized
  • Dimming Curve Modes: Variable 16-bit
  • High Speed Electronic Shutter and Strobe
  • Pan Angle: 540°/630°
  • Tilt Angle: 250°
• Color
  • Color Array: RGBMA
  • Emulation: CMY
  • Variable CCT: 2400K - 8500K
  • Green/Magenta Shift
  • Virtual Gel Swatch Book
• Gobos
  • Rotating/Indexing Interchangeable: 2x 6 Glass Gobos
  • Fixed Interchangeable: 7 Glass Gobos
  • Animation Wheel
• Control
  • DMX Channel Modes: 4 (RGBMA 34/44) (CMY 32/40)
  • Pan, Tilt, and Dimming Control: 16-bit
  • DMX Adjustable LED Frequency
  • Protocol Support: DMX, RDM, Art-NET, sACN
  • Control Panel: 4 Button Touch
  • Menu Display: Full Color 180° Reversible LCD
  • Adjustable Movement: 16-Bit Resolution
• Connections
  • DMX In/Out: 5-pin
  • Ethernet In/Out: Locking
  • Power Cable In: IP65 Locking
  • Wired Digital Communication Network
• Electrical/Thermal
  • AC 100-240V - 50/60Hz
  • Max Power Consumption: 1214W
  • Operating Temp.: 14°F - 113°F (-10°C - 45°C)
  • BTU/hr (+/- 10%): 3839.66
• Approvals/Ratings
  • CE, cETLus
  • IP Rating: IP20
• Physical
  • Length: 18.19” (462 mm)
  • Width: 21.26" (540 mm)
  • Width with Snoot: 23.2" (590 mm)
  • Vertical Height: 28.3" (719 mm)
  • Vertical Height with Snoot: 30.4" (771 mm)
  • Weight: 76.2 lbs (34.5 kg)
