Elation Lighting

DTW Bar 1000; 12 x 10W Dim to Warm / Dynamic White Bar

DTW Bar 1000; 12 x 10W Dim to Warm / Dynamic White Bar

$756.00 USD
$990.00 USD $756.00 USD
Sale Sold out

The DTW BAR 1000™ features (12) 10W multi-chip Cool White / Warm White / Amber LEDs, 20° beam 40° field angles, selectable dim-to-warm control, cool white, warm white, and amber color mixing, full pixel and 1,600K - 6,500K color temperature control, variable 16-bit dimming curve modes, selectable color and program macros, strobe and chase effects, DMX, RDM, KlingNet, and Art-Net protocol support, DMX, RJ45, and Locking Power in/out connections, LCD menu display with 4 button control panel, integrated dual rigging brackets, multiple unit power linking, rugged die-cast aluminum exterior, included frost filter and glare shield, flicker free operation for TV and FILM, and a multi-voltage universal auto switching power supply (110-240v).

Specifications



SOURCE

(12) 10W Multi-Chip CW / WW / Amber LEDs

100,000 Hour Average LED Life*

*May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.


PHOTOMETRIC DATA

2,900+ Total Output Lumens

17,878 LUX 1,661 FC @3.3’ (1m) (Full ON)

9,467 LUX 879 FC @3.3’ (1m) (Warm White)

9,177 LUX 853 FC @3.3’ (1m) (Cool White)


EFFECTS

Selectable Dim-to-Warm Control

Cool White, Warm White, Amber Color Mixing

Full Pixel + Color Temperature Control (1,600K - 6,500K)

Variable 16-bit Dimming Curve Modes

Selectable Color and Program Macros


CONTROL / CONNECTIONS

(14) DMX Channel Modes (72 total channels)

4 Button Control Panel and LCD Menu Display

RDM (Remote Device Management)

ArtNet + KlingNET Protocol Support

(2) ethernet RJ45 In/Out

3pin and 5pin DMX In/Out

Locking Power Cable In/Out


SIZE / WEIGHT

Length: 35.4” (900mm)

Width: 8.1” (206.4mm) *with included glare shield

Vertical Height: 6.1” (155mm)

Weight: 14.0 lbs. (6.4 kg)


ELECTRICAL / THERMAL

AC 110-240V - 50/60Hz

120W Max Power Consumption

5°F to 113°F (-15°C to 45°C)


APPROVALS / RATINGS



CE | cETLus | IP20


FIRMWARE UPDATES

Current Version: V1.13
